Pin / KUBOTA KX20 U20 (various pin locations)

Pin / KUBOTA KX20 U20 (various pin locations)

Kubota
  • Pin Locations
  • Make
Contact Us
Price
$ 0.00 $ 0.00
(Tax excluded)
Pin Locations P1: Boom Cylinder (Bottom), P2: Boom Base, P4: Boom Cylinder (Top), P5: Boom to Arm, P7: Bucket Cylinder (Top), P9: Arm to Bucket, P12K: King Post/Swing Bracket Pin and Bush Kit, U20-3 / P11 H-link (Bucket End)
Make Kubota
Make: Kubota

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
