Pin / KUBOTA KX15 U15 (various pin locations)

Pin / KUBOTA KX15 U15 (various pin locations)

Kubota
  • Pin Locations
  • Make
Contact Us
Price
$ 0.00 $ 0.00
(Tax excluded)
Pin Locations P1/P4: Boom Cylinder (Bottom) & Boom Cylinder (Top), P3: Arm Cylinder (Rear), P5: Boom to Arm, P6/P7: Arm Cylinder (Front) & Bucket Cylinder (Top), P12K: King Post/Swing Bracket Pin and Bush Kit, P13: Swing Cylinder Pin / Slew Ram Pin, P14: Balde Cylinder Pin, KX15 U15 / P8 (30x192.5) Side Link (Dipper Arm) (old), KX15 U15 / P10 (30x192.5) Bucket Cylinder (Bottom) (old), KX15 U15 / P8 (30x181.5) Side Link (Dipper Arm) (new), KX15 U15 / P10 (30x181.5) Bucket Cylinder (Bottom) (new), KX15 U15 / P9 & P11 (30x181) Arm to Bucket & H-link (Bucket End)
Make Kubota
Make: Kubota

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
