Pin / KOMATSU PC60 PC60-8 (various pin locations)

Pin / KOMATSU PC60 PC60-8 (various pin locations)

Komatsu
  • Pin Locations
  • Make
Contact Us
Price
$ 0.00 $ 0.00
(Tax excluded)
Pin Locations PC60 / P1 Boom Cylinder (Bottom), PC60 / P2 Boom Base, PC60 / P3 Arm Cylinder (Rear), PC60-8 / P3 Arm Cylinder (Rear), PC60 / P4 Boom Cylinder (Top), PC60 / P5 Boom to Arm, PC60 / P6 Arm Cylinder (Front), PC60 / P7 Bucket Cylinder (Top), PC60-8 / P7 Bucket Cylinder (Top), PC60 / P8 Side Link (Dipper Arm), PC60 / P10 Bucket Cylinder (Bottom), PC60 / P9 & P11 Arm to Bucket & H-link (Bucket End)
Make Komatsu
Make: Komatsu

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
