Pin / KUBOTA KX20 U20 (various pin locations)

Pin / KUBOTA KX20 U20 (various pin locations)

Kubota
  • Pin Locations
  • Make
Price
$ 0.00 $ 0.00
(Tax excluded)

Pin Locations KX20 U20 / P9 & P11 (30x191.5) Arm to Bucket & H-link (Bucket End), More options are coming.
Make Kubota
Request a Quote
Make: Kubota

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
