Pin / VOLVO EC55 (various pin locations)

Pin / VOLVO EC55 (various pin locations)

Volvo
$ 0.00 $ 0.00
(Tax included)

  • Pin Locations
  • Make
Pin Locations EC55 / P1 (55x180) Boom Cylinder (Bottom), EC55 / P2 (50x435) Boom Base, EC55 / P3 (50x167) Arm Cylinder (Rear), EC55 / P4 (55x220) Boom Cylinder (Top), EC55 / P5 (50x255) Boom to Arm, EC55 / P6 (50x150) Arm Cylinder (Front), EC55 / P7 (45x140) Bucket Cylinder (Top), EC55 / P8 & P10 (45x290) Side Link (Dipper Arm) & Bucket Cylinder (Bottom), EC55 / P9 & P11 (45x290) Arm to Bucket & H-link (Bucket End)
Make Volvo
Request a Quote
Make: Volvo

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
