Pin / KUBOTA KX135 (various pin locations)

Pin / KUBOTA KX135 (various pin locations)

Kubota
$ 0.00 $ 0.00
(Tax included)

  • Pin Locations
  • Make
Pin Locations KX135 / P8 (40x206) Side Link (Dipper Arm), KX135 / P10 (40x206) Bucket Cylinder (Bottom), KX135 / P9 & P11 (40x216) Arm to Bucket & H-link (Bucket End)
Make Kubota
Request a Quote
Make: Kubota

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
