Pin / KOMATSU PC30 (various pin locations)

Pin / KOMATSU PC30 (various pin locations)

Komatsu
$ 0.00 $ 0.00
(Tax included)

  • Pin Locations
  • Make
Pin Locations PC30 / P8 (35x215) Side Link (Dipper Arm), PC30 / P10 (35x215) Bucket Cylinder (Bottom), PC30 / P9 & P11 (35x240) Arm to Bucket & H-link (Bucket End)
Make Komatsu
Request a Quote
Make: Komatsu

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
