Pin / KOBELCO SK60-8 (various pin locations)

Pin / KOBELCO SK60-8 (various pin locations)

Kobelco
$ 0.00 $ 0.00
(Tax included)

  • Pin Locations
  • Make
Pin Locations SK60-8 / P8 (45x226) Side Link (Dipper Arm), SK60-8 / P10 (45x226) Bucket Cylinder (Bottom), SK60-8 / P9 & P11 (45x300) Arm to Bucket & H-link (Bucket End)
Make Kobelco
Request a Quote
Make: Kobelco

Pin Locations Diagram


P1: ​​Boom Cylinder (Bottom)
P2: Boom Base
P3: Arm Cylinder (Rear)
P4: Boom Cylinder (Top)
P5: Boom to Arm
P6: Arm Cylinder (Front)
P7: Bucket Cylinder (Top)
P8: Side Link (Dipper Arm)
P9: Arm to Bucket
P10: Bucket Cylinder (Bottom)
P11: H-link (Bucket End)​
